Diamond Micropowder RHW-B W10
Synthetic diamond micro powder product introduction:
1.Synthetic diamond powder:RHW series diamond powder refers to specifications in W50.W40.W28.W20.W14.W10.W7.W5.W3.5W2.5W1.5W1.W0.5W0.25(0.1um–43um)(5 micron-60 micron)particle size range using high-grade artificial diamond RHD as raw material,the diamond powder produced is widely used in cutting,grinding and other fields of organic and inorganic materials.
The application range of diamond micropowder is very wide including but not limited to the following fields:
Abrasives and polishing fields:Because diamond micropowder has super-hard wear-resistant and corrosion-resistant mechanical properties it can be used as an abrasive or polishing material for grinding cutting polishing and other processing processes.It can be widely used in clean energy,consumer electronics Semiconductors,ceramic stones oil and gas exploration geological drilling mechanical processing and other fields.
Functional materials field:Using diamond’s special properties in light electricity sound magnetism heat etc various functional materials can be made For example its high thermal conductivity can be used to make heat sink materials for lasers and optoelectronic devices Optical properties can be used to make optical devices and its superconducting properties can be used to make superconducting materials.
Tool manufacturing field:Using the excellent properties of diamond powder various diamond tools can be made such as cutting discs drill bits grinding stones coated abrasives etc which are widely used in construction geological drilling oil and gas mining ceramic stone and other fields.
In general with the continuous development of science and technology diamond powder has broad application prospects not only in traditional industrial fields but also in high-tech fields such as aerospace national defense and biomedicine.
Diamond micro powder basic particle size comparison table:
| 粒度
|
中国国标号 | 尺寸μm | 日本国标号 | 尺寸μm | 欧洲国标号 | 尺寸μm |
| M36/54 | W40 | 36/54 | 400 | 34/38 | D45 | 40/50 |
| M22/36 | 22/36 | 500 | 28/34 | D35 | 32/40 | |
| M20/30 | W28 | 20/30 | 600 | 24/28 | D25 | 25/32 |
| M12/22 | 12/22 | 700 | 20/24 | D20 | 25/40 | |
| M10/20 | W20 | 10/20 | 800 | 16/20 | D20A | 25/30 |
| M8/16 | 8/16 | 1000 | 13/16 | D20B | 30/40 | |
| M8/12 | 8/12 | |||||
| M6/12 | W14 | 6/12 | 1200 | 10/13 | D15 | 15/25 |
| M5/10 | W10 | 5/10 | 1500 | 8/10 | D15A | 10/15 |
| M4/8 | W7 | 4/8 | 2000 | 6/8 | D15B | 15/20 |
| M3/6 | 3/6 | 2500 | 5/6 | D15C | 20/25 | |
| M2.5/5 | W5 | 2.5/5 | 3000 | 4/5 | D7 | 5/10 |
| M2/4 | 2/4 | 4000 | 3/4 | D3 | 2/5 | |
| M1.5/3 | W3 | 1.5/3 | 5000 | 2/3 | D1 | 1/2 |
| M1/2 | W1.5 | 1/2 | 8000 | 1/2 | D0.7 | 0.5/1 |
| M0/2 | 0/2 | |||||
| M0.5/1.5 | W1 | 0.5/1.5 | 15000 | 0/1 | D0.25 | 0.5 |
| M0.5/1 | 0.5/1 | |||||
| MO/1 | 0/1 | |||||
| M0/0.5 | 0/0.5 |
